Microprocessor 8085 program to find 1's complement

In the third year of the B.Sc. Physics practical program under TANSCHE, it's crucial to grasp how microprocessors work. A significant part of this involves the Microprocessor 8085, which is a popular 8-bit processor. In this experiment, students get to practice basic arithmetic operations.

This blog post will highlight the experiment on finding the 1's complement of 8-bit/16-bit Numbers using the Microprocessor 8085. This hands-on activity helps students dive into the essential features of the 8085 microprocessor, including programming logic and memory functions. By completing this task, you'll develop a clear understanding of how the 8085 processes data and performs arithmetic operations, laying a strong groundwork in microprocessor systems.

Microprocessor 8085 program to find 1's complement

Aim:

Write an assembly language program to find 1’s complement numbers using microprocessor 8085.

Apparatus required:

Microprocessor 8085 kit, power supply etc

Program:

1’s complement of 8-bit

Memory address	Machine code	Mnemonics	Operands	Comments
8000	3A	LDA	8501H	Load the data in accumulator
8001	01
8002	85
8003	2F	CMA		Complement the accumulator
8004	32	STA	8502H	Store the result in the memory location 8502
8005	02
8006	85
8007	76	HLT		Stop the program

Example:

1’s complement of 8-bit number

First input location 8501H - 14H (In binary form 0001 0100)

Result location 8502H - EBH (In binary form (1110 1011)

YouTube Demo:

1’s complement of 16-bit

Memory address	Machine code	Mnemonics	Operands	Comments
8000	21	LXI	H, 8501H	Address of the LSB of the number
8001	01
8002	85
8003	7E	MOV	A, M	Move the number to the accumulator
8004	2F	CMA		Complement the accumulator
8005	32	STA	8503H	Store the result in the accumulator in the location 8503H
8006	03
8007	85
8008	23	INX	H	Increment C register
8009	7E	MOV	A, M	Move the content of C register to accumulator
800A	32	STA	8504H	Store the result in the accumulator in the location 8504H
800B	04
800C	85
800D	76	HLT		Stop the program

Example:

1’s complement of 16-bit number

First input location 8501H - 14H (In binary form 0001 0100)

Second input location 8502H - 15H (In binary form 0001 0101)

Result location 8503H - EBH (In binary form (1110 1011)

Result location 8504H - EAH (In binary form (1110 1010)

YouTube Demo:

Procedure:

Result:

The assembly programmes for microprocessor 8085 for finding 1's complement of 8-bit and 16-bit numbers were written and executed using the microprocessor 8085 kit.
